Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Built-in depth75.5mm
Rated voltage240V
Voltage typeAC
Release characteristicB
Rated current13A
Current limiting class3
Surge current capacity3kA
Rated insulation voltage Ui500V
Over voltage category3
Rated fault current0.03A
Degree of protection (IP)IP20
Frequency50 Hz
Pollution degree2
Leakage current typeA
Width in number of modular spacings2
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorYes
Number of protected poles1
Rated short-circuit breaking capacity according to IEC 60947-26kA
Connectable conductor cross section solid-core1 - 25mm²
Connectable conductor cross section multi-wired1 - 25mm²
Anti-nuisance tripping versionYes
Ambient temperature during operating-25 - 40°C
Number of poles (total)2
Rated short-circuit breaking capacity according to EN 610096kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Disconnection characteristicShort-time delayed
With interlocking deviceNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-B13/1N/003-G/A
