Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Built-in depth75.5mm
Rated voltage415V
Release characteristicB
Rated insulation voltage Ui500V
Degree of protection (IP)IP20
Frequency50 Hz
Over voltage category3
Current limiting class3
Width in number of modular spacings4
Surge current capacity0.25kA
Pollution degree2
Flush-mounted installationNo
With interlocking deviceNo
Number of protected poles4
Connectable conductor cross section solid-core1 - 25mm²
Concurrently switching neutral conductorYes
Anti-nuisance tripping versionNo
Connectable conductor cross section multi-wired1 - 25mm²
Disconnection characteristicUndelayed
Rated short-circuit breaking capacity according to EN 610096kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Ambient temperature during operating-25 - 40°C
Rated short-circuit breaking capacity according to IEC 60947-20kA
Rated current13A
Rated fault current0.1A
Leakage current typeAC
Number of poles (total)4
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-B13/3N/01
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Voltage type
AC
Built-in depth
75.5mm
Rated voltage
415V
Release characteristic
B
Rated insulation voltage Ui
500V
Degree of protection (IP)
IP20
Frequency
50 Hz
Over voltage category
3
Current limiting class
3
Width in number of modular spacings
4
Surge current capacity
0.25kA
Pollution degree
2
Flush-mounted installation
With interlocking device
Number of protected poles
4
Connectable conductor cross section solid-core
1 .. 25mm²
Concurrently switching neutral conductor
Anti-nuisance tripping version
Connectable conductor cross section multi-wired
1 .. 25mm²
Disconnection characteristic
Undelayed
Rated short-circuit breaking capacity according to EN 61009
6kA
Rated impulse withstand voltage Uimp
4kV
Rated short-circuit breaking capacity Icn according to EN 61009-1
6kA
Ambient temperature during operating
-25 .. 40°C
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Rated current
13A
Rated fault current
0.1A
Leakage current type
AC
Number of poles (total)
4
