Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Built-in depth75.5mm
Rated current6A
Rated insulation voltage Ui500V
Rated voltage240V
Current limiting class3
Surge current capacity0.25kA
Release characteristicC
Pollution degree2
Over voltage category3
Connectable conductor cross section multi-wired1 - 25mm²
Rated fault current0.3A
Leakage current typeAC
With interlocking deviceNo
Number of poles (total)2
Flush-mounted installationNo
Anti-nuisance tripping versionNo
Number of protected poles1
Rated short-circuit breaking capacity according to IEC 60947-20kA
Ambient temperature during operating-25 - 40°C
Rated impulse withstand voltage Uimp4kV
Connectable conductor cross section solid-core1 - 25mm²
Frequency50 Hz
Degree of protection (IP)IP20
Concurrently switching neutral conductorYes
Width in number of modular spacings2
Rated short-circuit breaking capacity Icn according to EN 61009-16kA
Disconnection characteristicUndelayed
Rated short-circuit breaking capacity according to EN 610096kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBm6-C6/1N/03
