Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Rated current6A
Voltage typeAC
Built-in depth75.5mm
Rated insulation voltage Ui500V
Rated voltage120V
Release characteristicC
Surge current capacity0.25kA
Over voltage category3
Pollution degree2
Rated fault current0.03A
Leakage current typeA
Current limiting class3
Frequency50 Hz
With interlocking deviceNo
Number of protected poles2
Rated short-circuit breaking capacity according to IEC 60947-20kA
Width in number of modular spacings2
Ambient temperature during operating-25 - 40°C
Connectable conductor cross section multi-wired1 - 25mm²
Degree of protection (IP)IP20
Concurrently switching neutral conductorNo
Connectable conductor cross section solid-core1 - 25mm²
Number of poles (total)2
Anti-nuisance tripping versionNo
Rated impulse withstand voltage Uimp4kV
Flush-mounted installationNo
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Rated short-circuit breaking capacity according to EN 6100910kA
Disconnection characteristicUndelayed
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBMM-C6/2/003-A-120
