Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Built-in depth75.5mm
Voltage typeAC
Rated current6A
Leakage current typeA
Over voltage category3
Surge current capacity0.25kA
Rated insulation voltage Ui500V
Frequency50 Hz
Current limiting class3
Rated voltage240V
Pollution degree2
Width in number of modular spacings2
Degree of protection (IP)IP20
Release characteristicC
Rated fault current0.03A
Number of poles (total)2
Rated short-circuit breaking capacity according to IEC 60947-20kA
Number of protected poles2
Concurrently switching neutral conductorNo
Rated impulse withstand voltage Uimp4kV
Connectable conductor cross section solid-core1 - 25mm²
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
With interlocking deviceNo
Anti-nuisance tripping versionNo
Connectable conductor cross section multi-wired1 - 25mm²
Flush-mounted installationNo
Disconnection characteristicShort-time delayed
Ambient temperature during operating-25 - 40°C
Rated short-circuit breaking capacity according to EN 6100910kA
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBmM-C6/2/003-LIA
