Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Leakage current typeAC
Voltage typeAC
Rated voltage240V
Rated current13A
Rated insulation voltage Ui500V
Release characteristicD
Rated fault current0.03A
Built-in depth75.5mm
Surge current capacity0.25kA
Over voltage category3
Current limiting class3
Pollution degree2
Degree of protection (IP)IP20
Width in number of modular spacings2
Concurrently switching neutral conductorYes
Frequency50 Hz
With interlocking deviceNo
Flush-mounted installationNo
Rated short-circuit breaking capacity according to IEC 60947-215kA
Connectable conductor cross section multi-wired1 - 25mm²
Connectable conductor cross section solid-core1 - 25mm²
Disconnection characteristicUndelayed
Ambient temperature during operating-25 - 40°C
Rated short-circuit breaking capacity according to EN 6100910kA
Anti-nuisance tripping versionNo
Rated impulse withstand voltage Uimp4kV
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Number of protected poles1
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBmM-D13/1N/003
