Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Rated insulation voltage Ui500V
Rated voltage415V
Surge current capacity0.25kA
Rated current6A
Rated fault current0.03A
Built-in depth75.5mm
Current limiting class3
Release characteristicD
Voltage typeAC
Leakage current typeA
Width in number of modular spacings4
Pollution degree2
Connectable conductor cross section multi-wired1 - 25mm²
Concurrently switching neutral conductorNo
Over voltage category3
Number of protected poles3
Degree of protection (IP)IP20
Rated short-circuit breaking capacity according to IEC 60947-215kA
Connectable conductor cross section solid-core1 - 25mm²
Frequency50 Hz
With interlocking deviceNo
Rated impulse withstand voltage Uimp4kV
Anti-nuisance tripping versionNo
Number of poles (total)3
Rated short-circuit breaking capacity according to EN 6100910kA
Disconnection characteristicUndelayed
Ambient temperature during operating-25 - 40°C
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
Flush-mounted installationNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBmM-D6/3/003-A
