Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker
- •1 KOM
- •EATON
Technical specifications
Surge current capacity0.25kA
Width in number of modular spacings4
Frequency50 Hz
Over voltage category3
Current limiting class3
Rated insulation voltage Ui500V
Number of protected poles3
Voltage typeAC
Connectable conductor cross section multi-wired1 - 25mm²
Rated current6A
Degree of protection (IP)IP20
Connectable conductor cross section solid-core1 - 25mm²
Concurrently switching neutral conductorNo
Release characteristicD
Rated fault current0.1A
Rated voltage415V
Rated short-circuit breaking capacity according to IEC 60947-215kA
Pollution degree2
Built-in depth75.5mm
Leakage current typeA
Number of poles (total)3
Rated short-circuit breaking capacity according to EN 6100910kA
Ambient temperature during operating-25 - 40°C
Anti-nuisance tripping versionNo
Disconnection characteristicUndelayed
Rated short-circuit breaking capacity Icn according to EN 61009-110kA
With interlocking deviceNo
Rated impulse withstand voltage Uimp4kV
Flush-mounted installationNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRBmM-D6/3/01-A
