Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Rated current80A
Short-circuit breaking capacity (Icw)10kA
Rated voltage415V
Rated insulation voltage Ui440V
Mounting methodDIN rail
Number of poles4
Voltage typeAC
Built-in depth70.5mm
Rated fault current0.3mA
Surge current capacity5kA
Selective protectionYes
Leakage current typeA
Short-time delayed trippingNo
Frequency50/60 Hz
Pollution degree2
Width in number of modular spacings4
Degree of protection (IP)IP20
RAL-number (similar)7035
Additional equipment possibleYes
Ambient temperature during operating-25 - 40°C
With interlocking deviceYes
Rated impulse withstand voltage Uimp4kV
Explosion-proofNo
Connectable conductor cross section multi-wired1.5 - 16mm²
Connectable conductor cross section solid-core1.5 - 35mm²
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRCmM-80/4/03-S/A
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Residual current circuit breaker (RCCB)
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Rated current
80A
Short-circuit breaking capacity (Icw)
10kA
Rated voltage
415V
Rated insulation voltage Ui
440V
Mounting method
DIN rail
Number of poles
4
Voltage type
AC
Built-in depth
70.5mm
Rated fault current
0.3mA
Surge current capacity
5kA
Selective protection
Leakage current type
A
Short-time delayed tripping
Frequency
50/60 Hz
Pollution degree
2
Width in number of modular spacings
4
Degree of protection (IP)
IP20
RAL-number (similar)
7035
Additional equipment possible
Ambient temperature during operating
-25 .. 40°C
With interlocking device
Rated impulse withstand voltage Uimp
4kV
Explosion-proof
Connectable conductor cross section multi-wired
1.5 .. 16mm²
Connectable conductor cross section solid-core
1.5 .. 35mm²
