Details
- •Earthing, lightning and surge protection
- •Surge protection device for power supply systems
- •1 KOM
- •EATON
Technical specifications
Voltage protection level1.4kV
Number of conductors (without earthing)0
Nominal voltage AC0V
Mounting methodOn basic element
With remote signalling contactNo
Construction size1 modular spacing
Nominal discharge surge current (8/20)15kA
Max. continuous voltage AC0V
Voltage protection level L-N0kV
Max. PV-voltage400V
Integrated backup fuseNo
Nominal voltage DC330V
Degree of protection (IP)IP20
Voltage protection level N-PE0kV
Signalling at the deviceOptic
Max. continuous voltage DC400V
Category type 2Yes
Max. conductor cross section solid (solid, stranded)0mm²
Max. conductor cross section flexible (fine-strand)0mm²
System configuration otherNo
System configuration TTNo
System configuration TN-CNo
System configuration TN-C-SNo
System configuration TNNo
System configuration ITYes
System configuration DCNo
System configuration TN-SNo
Integrated short-circuit protectionNo
Integrated short-circuit protection selective to fuse gG0A
Max. overcurrent protection device, series connection (fuse)0A
Max. discharge surge current (8/20)40kA
Max. overcurrent protection device, parallel connection (fuse)0A
Leakage-current freeNo
Short-circuit breaking capacity (Isccr)0kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
SPPVT2-06
