Details
- •Cables
- •Data and communication cable
- •1 KOM
- •EATON
Technical specifications
Material core insulationOther
UV resistantNo
Nominal cross section conductor0.5mm²
Stranding elementPairs
Cable typeOther
Drain wireNo
Conductor materialOther
Nominal voltage U24V
Characteristic impedance100Ohm
Screen over strandingNone
Screen over stranding elementFoil
CategoryOther
Number of cores5
Material outer sheathPolyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration-40 - 80°C
Halogen free (according to IEC 60754-2)No
Protective sheathOther
Armouring/reinforcementNone
Diameter conductor1.5mm
Conductor categoryClass 2 = stranded
Suitable for underground installationNo
Number of stranding elements5
Permitted cable outer temperature during assembling/handling-40 - 80°C
Colour outer sheathGreen
Core identificationColour
Low smoke (according to IEC 61034-2)No
Cable width approx.5.6mm
Cable height approx.16.3mm
StrandingBundle
Outer diameter approx.5.6mm
Radial water blocking cableYes
Min. permitted bending radius, moving application with forced guidance46mm
Specification core insulationOther
Euro class flaming droplets/particles according to EN 13501-6None
Smoke development class according to EN 13501-6None
With rodent protectionNo
Cable geometryRound
Longitudinal water blocking cableNo
AWG size20
Min. permitted bending radius, stationary application/permanent installation34mm
Min. permitted bending radius, moving application/free movement46mm
Specification material outer sheathPolypropylene (PP)
Material reinforcementOther
Conductor surfaceBare
Euro class acidity according to EN 13501-6None
Oil resistant (according to EN 60811-404)Yes
Reaction-to-fire class according to EN 13501-6None
NVP value66.5%
Certified for shipboard applicationNo
Suitable as signalling cableYes
Suitable as computer data cableNo
Core identification according to HD 308 S2No
Suitable as telephone cableNo
Flame retardant according to IEC 60332-3-23 (Cat B)No
Approved type of underground installationOther
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
Flame retardant according to IEC 60332-3-22 (Cat A)No
Flame retardant according to IEC 60332-3-24 (Cat C)No
Number of sheath layers0
With rip cordNo
Flame retardant according to IEC 60332-3-25 (Cat D)No
Suitable for use as security alarm cableNo
Compatible with Grade3TV according to XP-C 90-483No
Halogen free according to IEC 60754-1No
Flame retardant according to IEC 60332-1-2No
Halogen free according to IEC 60754-3No
Circuit integrity according to IEC 60331-23No
DuplexNo
Compatible with Grade2TV according to XP-C 90-483No
