Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Number of poles4
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu20A
Width100mm
Depth136mm
Rated operation power at AC-3, 400 V5.5kW
Number of auxiliary contacts as normally closed contact0
Height181mm
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq6kA
Colour control elementBlack
Degree of protection (IP), front sideIP65
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeNo
Number of switches1
InterlockableYes
Version as emergency stop installationNo
Type of electrical connection of main circuitScrew connection
Rated operation power at AC-23, 400 V5.5kW
Motor drive integratedNo
Suitable for intermediate mountingNo
Suitable for distribution board installationNo
Type of control elementDoor coupling rotary drive
Version as maintenance-/service switchYes
Suitable for floor mountingYes
Suitable for front mounting centreNo
Rated short-time withstand current lcw0.32kA
Version as safety switchNo
Max. rated operation voltage Ue AC690V
Voltage release optionalNo
Rated permanent current at AC-21, 400 V20A
Device constructionComplete device in housing
Motor drive optionalNo
Version as main switchYes
Switching power at 400 V5.5kW
Degree of protection (NEMA)12
Rated permanent current at AC-23, 400 V13.3A
Version as reversing switchNo
With pre-assembled cablingNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
T0-2-8900/I2H/MBS/SVB-SW
