Details
- •Programmable logic controllers PLC
- •Fieldbus, decentr. periphery - digital I/O module
- •1 KOM
- •EATON
Technical specifications
Suitable for safety functionsNo
Depth98mm
Height20.1mm
Input current at signal 14mA
Width56.9mm
Number of HW-interfaces USB0
Supporting protocol for KNXNo
Number of HW-interfaces RS-4220
Supporting protocol for CANNo
Number of HW-interfaces serial TTY0
Supporting protocol for Data-HighwayNo
Type of voltage (input voltage)DC
Number of digital inputs2
Supporting protocol for ModbusNo
Number of digital outputs0
Supporting protocol for INTERBUSNo
Supporting protocol for ASINo
Number of HW-interfaces RS-2320
Supporting protocol for LONNo
Supporting protocol for DeviceNetNo
Number of HW-interfaces parallel0
Number of HW-interfaces other0
With optical interfaceNo
Number of HW-interfaces RS-4850
Supporting protocol for TCP/IPNo
Voltage type of supply voltageDC
Time delay at signal exchange0 - 0.2ms
Supporting protocol for PROFIBUSNo
Supporting protocol for SUCONETNo
Number of HW-interfaces industrial Ethernet0
Short-circuit protection, outputs availableNo
Explosion safety category for dustNone
Explosion safety category for gasNone
Supporting protocol for SERCOSNo
Rack-assembly possibleNo
IO link masterNo
Radio standard BluetoothNo
Wall mounting/direct mountingYes
Type of digital outputNone
Supporting protocol for INTERBUS-SafetyNo
Type of electric connectionScrew connection
Output current0A
Radio standard Wi-Fi 802.11No
Number of HW-interfaces Wireless0
Supporting protocol for other bus systemsYes
Appendant operation agent (Ex ib)No
Rail mounting possibleYes
Degree of protection (IP)IP69K
Front built-in possibleNo
Number of interfaces PROFINET0
Appendant operation agent (Ex ia)No
Fieldbus connection over separate bus coupler possibleYes
Performance level according to EN ISO 13849-1None
System accessoryYes
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for EtherNet/IPNo
Supply voltage AC 50 Hz0 - 0V
Supporting protocol for PROFINET IONo
Supporting protocol for PROFIsafeNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET CBANo
Supply voltage AC 60 Hz0 - 0V
Supporting protocol for Foundation FieldbusNo
Supply voltage DC0 - 28.8V
Certified for UL hazardous location division 2No
Radio standard UMTSNo
Supporting protocol for EtherCATNo
Certified for UL hazardous location class INo
Certified for UL hazardous location class IIINo
Permitted voltage at input20.4 - 28.8V
Radio standard GPRSNo
Radio standard GSMNo
Type of output voltageDC
Certified for UL hazardous location division 1No
Permitted voltage at output20.4 - 28.8V
Digital outputs configurableNo
SIL according to IEC 61508None
Digital inputs configurableNo
Certified for UL hazardous location class IINo
Certified for UL hazardous location group B (hydrogen)No
Certified for UL hazardous location group D (propane)No
Certified for UL hazardous location group C (ethylene)No
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group G (non-conductive dusts)No
Certified for UL hazardous location group E (metal dusts)No
Certified for UL hazardous location group A (acetylene)No
