Details
- •Low-voltage industrial components
- •Switch disconnector (low voltage)
- •1 KOM
- •EATON
Technical specifications
Height84mm
Rated operation power at AC-3, 400 V37kW
Width100mm
Depth340mm
Colour control elementGrey
Version as main switchYes
Rated operation power at AC-23, 400 V55kW
Rated operating voltage690 - 690V
InterlockableYes
Version as safety switchNo
Version as emergency stop installationNo
Type of electrical connection of main circuitScrew connection
Version as maintenance-/service switchYes
Degree of protection (IP), front sideIP65
Type of control elementShort thumb-grip
Rated short-time withstand current lcw2kA
Suitable for front mounting centreNo
Rated permanent current Iu100A
Number of auxiliary contacts as change-over contact0
Suitable for distribution board installationNo
Number of poles3
Number of auxiliary contacts as normally closed contact0
Conditioned rated short-circuit current Iq80kA
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Motor drive integratedNo
Number of auxiliary contacts as normally open contact0
Suitable for intermediate mountingYes
Number of switches1
With pre-assembled cablingNo
Motor drive optionalNo
Rated permanent current at AC-23, 400 V100A
Voltage release optionalNo
Switching power at 400 V55kW
Rated permanent current at AC-21, 400 V100A
Max. rated operation voltage Ue AC690V
Degree of protection (NEMA)12
Device constructionBuilt-in device fixed built-in technique
Version as reversing switchNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P3-100/M4/K2-PG
