Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V30kW
Conditioned rated short-circuit current Iq4kA
Number of poles3
Rated operating voltage690 - 690V
Number of auxiliary contacts as normally closed contact1
Number of auxiliary contacts as normally open contact1
Rated permanent current Iu63A
Number of switches1
Number of auxiliary contacts as change-over contact0
Suitable for front mounting 4-holeNo
Version as maintenance-/service switchYes
Type of electrical connection of main circuitScrew connection
Version as safety switchNo
Type of control elementToggle
InterlockableYes
Suitable for floor mountingYes
Version as emergency stop installationNo
Version as main switchYes
Rated permanent current at AC-21, 400 V63A
Rated operation power at AC-23, 400 V30kW
Suitable for distribution board installationNo
Suitable for front mounting centreNo
Colour control elementRed
Device constructionBuilt-in device fixed built-in technique
Rated short-time withstand current lcw1.26kA
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Motor drive integratedNo
Suitable for intermediate mountingYes
Voltage release optionalNo
Switching power at 400 V30kW
Degree of protection (IP), front sideIP65
Version as reversing switchNo
Rated permanent current at AC-23, 400 V63A
Degree of protection (NEMA)Other
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P3-63/M4/K2-PR/HI11
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Rated operation power at AC-3, 400 V
30kW
Conditioned rated short-circuit current Iq
4kA
Number of poles
3
Rated operating voltage
690 .. 690V
Number of auxiliary contacts as normally closed contact
1
Number of auxiliary contacts as normally open contact
1
Rated permanent current Iu
63A
Number of switches
1
Number of auxiliary contacts as change-over contact
0
Suitable for front mounting 4-hole
Version as maintenance-/service switch
Type of electrical connection of main circuit
Screw connection
Version as safety switch
Type of control element
Toggle
Interlockable
Suitable for floor mounting
Version as emergency stop installation
Version as main switch
Rated permanent current at AC-21, 400 V
63A
Rated operation power at AC-23, 400 V
30kW
Suitable for distribution board installation
Suitable for front mounting centre
Colour control element
Red
Device construction
Built-in device fixed built-in technique
Rated short-time withstand current lcw
1.26kA
Max. rated operation voltage Ue AC
690V
Motor drive optional
Motor drive integrated
Suitable for intermediate mounting
Voltage release optional
Switching power at 400 V
30kW
Degree of protection (IP), front side
IP65
Version as reversing switch
Rated permanent current at AC-23, 400 V
63A
Degree of protection (NEMA)
Other
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
