Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated permanent current Iu63A
Number of auxiliary contacts as normally open contact1
Number of poles4
Rated operation power at AC-3, 400 V30kW
Rated operating voltage690 - 690V
Degree of protection (IP), front sideIP65
Conditioned rated short-circuit current Iq4kA
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally closed contact1
Max. rated operation voltage Ue AC690V
Type of electrical connection of main circuitScrew connection
Version as safety switchNo
Suitable for intermediate mountingYes
Rated operation power at AC-23, 400 V30kW
InterlockableYes
Version as emergency stop installationNo
Motor drive integratedNo
Version as maintenance-/service switchYes
Type of control elementToggle
Version as main switchYes
Colour control elementRed
Suitable for front mounting 4-holeNo
Suitable for front mounting centreNo
Suitable for floor mountingYes
Suitable for distribution board installationNo
Rated short-time withstand current lcw1.26kA
Number of switches1
Device constructionBuilt-in device fixed built-in technique
Version as reversing switchNo
Rated permanent current at AC-21, 400 V63A
Voltage release optionalNo
Motor drive optionalNo
Rated permanent current at AC-23, 400 V63A
Switching power at 400 V30kW
Degree of protection (NEMA)Other
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
P3-63/M4/K2-PR/N/HI11
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Rated permanent current Iu
63A
Number of auxiliary contacts as normally open contact
1
Number of poles
4
Rated operation power at AC-3, 400 V
30kW
Rated operating voltage
690 .. 690V
Degree of protection (IP), front side
IP65
Conditioned rated short-circuit current Iq
4kA
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally closed contact
1
Max. rated operation voltage Ue AC
690V
Type of electrical connection of main circuit
Screw connection
Version as safety switch
Suitable for intermediate mounting
Rated operation power at AC-23, 400 V
30kW
Interlockable
Version as emergency stop installation
Motor drive integrated
Version as maintenance-/service switch
Type of control element
Toggle
Version as main switch
Colour control element
Red
Suitable for front mounting 4-hole
Suitable for front mounting centre
Suitable for floor mounting
Suitable for distribution board installation
Rated short-time withstand current lcw
1.26kA
Number of switches
1
Device construction
Built-in device fixed built-in technique
Version as reversing switch
Rated permanent current at AC-21, 400 V
63A
Voltage release optional
Motor drive optional
Rated permanent current at AC-23, 400 V
63A
Switching power at 400 V
30kW
Degree of protection (NEMA)
Other
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
