Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •SOCOMEC
Technical specifications
Number of auxiliary contacts as normally open contact3
Rated operation power at AC-3, 400 V-kW
Number of auxiliary contacts as normally closed contact0
Number of poles4
Rated permanent current Iu2500A
Conditioned rated short-circuit current Iq-kA
Degree of protection (IP), front sideIP20
Suitable for floor mountingYes
Rated operation power at AC-23, 400 V-kW
Version as main switchNo
Rated operating voltage400 - 690V
Rated short-time withstand current lcw50kA
InterlockableYes
Number of switches2
Version as emergency stop installationNo
Motor drive integratedYes
Version as maintenance-/service switchNo
Type of control elementLong turning handle
Suitable for front mounting 4-holeYes
Colour control elementBlack
Type of electrical connection of main circuitBolt connection
Number of auxiliary contacts as change-over contact4
Version as safety switchNo
Suitable for front mounting centreNo
Motor drive optionalNo
Suitable for intermediate mountingYes
Max. rated operation voltage Ue AC1000V
Voltage release optionalNo
Device constructionBuilt-in device fixed built-in technique
Suitable for distribution board installationYes
Version as reversing switchYes
Rated permanent current at AC-21, 400 V2500A
Rated permanent current at AC-23, 400 V1600A
Switching power at 400 V-kW
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
95234250 | ATyS / ATyS r 4X2500A F
