Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •1 KOM
- •ABB
Technical specifications
Degree of protection (IP)IP20
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
Number of protected poles2
Additional equipment possibleYes
Connectable conductor cross section solid-core0 - 50mm²
Concurrently switching neutral conductorNo
Connectable conductor cross section multi-wired0 - 50mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Width in number of modular spacings2
Pollution degree3
Release characteristicC
Rated current80A
Number of poles (total)2
Frequency50 - 60Hz
Over voltage category3
Suitable for flush-mounted installationNo
Rated insulation voltage Ui440V
Ambient temperature during operating-25 - 55°C
Rated voltage110V
Built-in depth69mm
Current limiting class3
Voltage typeAC/DC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Rated impulse withstand voltage Uimp4kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDS252001R0804 | S202-C80
