2CDS253001R0805 | S203-B80
Code: 1661222
ManufacturerABB
Catalog number2CDS253001R0805
TypeS203-B80
CategoryMiniature circuit breaker (MCB)
EAN code4016779917711
Details
- •MINIJATURNI PREKIDAC, 3P, 80A, B KRIVULJA, 10kA
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Width in number of modular spacings3
Voltage typeAC
Power loss24.3W
Built-in depth69mm
Over voltage category3
Explosion-proofNo
Degree of protection (IP)IP20
Pollution degree3
Rated voltage400V
Rated insulation voltage Ui440V
Current limiting class3
Frequency50 - 60Hz
Number of protected poles3
Concurrently switching neutral conductorNo
Additional equipment possibleYes
Connectable conductor cross section solid-core0 - 50mm²
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20kA
Rated impulse withstand voltage Uimp4kV
Ambient temperature during operating-25 - 55°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6kA
Connectable conductor cross section multi-wired0 - 50mm²
Flush-mounted installationNo
Rated current80A
Release characteristicB
Number of poles (total)3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6kA
