Details
- •Relays
- •Device for monitoring of safety-related circuits
- •1 KOM
- •ABB
Technical specifications
Power consumption-W
Control voltage 224 - 24V
Release-delay48 - 48s
Type of control voltage 2DC
Number of outputs, safety related, delayed, with contact0
Number of outputs, safety related, undelayed, with contact2
With approval according to ULNo
Height84mm
ModelOther
With start inputYes
With detachable clampsYes
With feedback circuitYes
Control voltage 124 - 24V
Type of control voltage 1DC
Depth120mm
Number of outputs, signalling function, delayed, semiconductors0
Number of outputs, signalling function, undelayed, with contact0
Number of outputs, safety related, undelayed, semiconductors0
Rail mounting possibleYes
Suitable for monitoring of tactile sensorsNo
Number of outputs, signalling function, delayed, with contact0
Suitable for monitoring of valvesYes
Type of electric connectionScrew connection
With approval for BG BIANo
Supply voltage AC 60 Hz- - -V
Number of outputs, safety related, delayed, semiconductors0
Stop category according to IEC 602040
Suitable for monitoring of proximity switchesYes
Suitable for monitoring of emergency-stop circuitsYes
Suitable for monitoring of optoelectronic protection equipmentYes
Number of outputs, signalling function, undelayed, semiconductors0
Voltage type (operating voltage)DC
With muting functionNo
Rated switch current-A
Suitable for monitoring of magnetic switchesYes
Suitable for monitoring of position switchesYes
With approval for TÜVYes
Evaluation inputs1-channel
Operating voltage at DC24 - 24V
SIL according to IEC 615083
Operating voltage at AC 50 Hz- - -V
Operating voltage at AC 60 Hz- - -V
Width22.5mm
Voltage type of supply voltageDC
Type of safety according to IEC 61496-14
Performance level according to EN ISO 13849-1Level e
Supply voltage AC 50 Hz- - -V
Supply voltage DC- - -V
