Details

  • •
  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Voltage typeAC
Built-in depth44mm
Rated voltage415V
Width in number of modular spacings3
Current limiting class3
Over voltage category4
Number of protected poles2
Explosion-proofNo
Pollution degree3
Frequency50 - 60Hz
Concurrently switching neutral conductorYes
Rated insulation voltage Ui500V
Degree of protection (IP)IP20
Flush-mounted installationNo
Ambient temperature during operating-25 - 70°C
Connectable conductor cross section solid-core1.5 - 50mm²
Additional equipment possibleYes
Connectable conductor cross section multi-wired1 - 35mm²
Rated impulse withstand voltage Uimp6kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V20kA
Rated current80A
Release characteristicC
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
