  • •Circuit breakers and fuses
  • •Miniature circuit breaker (MCB)
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Rated current5A
Degree of protection (IP)IP20
Voltage typeDC
Pollution degree2
Current limiting class-
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V-kA
Rated voltage800V
Release characteristicC
Number of protected poles2
Number of poles (total)2
Width in number of modular spacings4
Additional equipment possibleYes
Suitable for flush-mounted installationNo
Concurrently switching neutral conductorYes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V1.5kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V-kA
Built-in depth77.4mm
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V1.5kA
Over voltage category4
Frequency50 - 50Hz
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user

A9N61656 | Prekidac za PV C60PV-DC 2P 5A 800VDC

Main Product Image

Why Register?

  • View wholesale prices with discounts
  • Real-time stock availability
  • Access invoices and dispatch notes
  • Order history and frequently ordered items
  • Exclusive B2B offers

and much more...

Details

  • Circuit breakers and fuses
  • Miniature circuit breaker (MCB)
  • 1 KOM
  • SCHNEIDER

Technical specifications

Rated current

5A

Degree of protection (IP)

IP20

Voltage type

DC

Pollution degree

2

Current limiting class

-

Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

-kA

Rated voltage

800V

Release characteristic

C

Number of protected poles

2

Number of poles (total)

2

Width in number of modular spacings

4

Additional equipment possible

Suitable for flush-mounted installation

Concurrently switching neutral conductor

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

1.5kA

Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

-kA

Built-in depth

77.4mm

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

1.5kA

Over voltage category

4

Frequency

50 .. 50Hz
