Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Number of digital inputs3
Width320mm
With control elementYes
Number of analogue inputs2
Number of HW-interfaces other0
Number of digital outputs0
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-4220
Number of HW-interfaces USB0
Supporting protocol for LONYes
Depth290mm
Number of HW-interfaces industrial Ethernet0
Supporting protocol for INTERBUSNo
Number of HW-interfaces RS-4851
Number of HW-interfaces RS-2320
Supporting protocol for ASINo
Supporting protocol for PROFIBUSNo
Supporting protocol for CANNo
Height630mm
With optical interfaceNo
Number of analogue outputs1
Number of HW-interfaces parallel0
Supporting protocol for TCP/IPNo
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Max. output frequency200Hz
Max. output at quadratic load at rated output voltage75kW
Application in industrial area permittedYes
Supporting protocol for DeviceNetNo
Number of interfaces PROFINET0
Type of converterU converter
Mains frequency50/60 Hz
Supporting protocol for SERCOSNo
Application in domestic- and commercial area permittedYes
With PC connectionYes
Relative symmetric net voltage tolerance10%
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net frequency tolerance5%
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for other bus systemsYes
Integrated breaking resistanceNo
Supporting protocol for INTERBUS-SafetyNo
4-quadrant operation possibleNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for PROFINET IONo
Supporting protocol for Foundation FieldbusNo
Max. output voltage480V
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Supporting protocol for PROFINET CBANo
Degree of protection (IP)IP21
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage75kW
Nominal output current I2N160A
