Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth364mm
Number of analogue inputs2
Height1000mm
Number of digital outputs0
With control elementYes
Width362mm
Number of digital inputs3
Number of HW-interfaces RS-4851
Number of HW-interfaces USB0
Supporting protocol for LONYes
Number of HW-interfaces industrial Ethernet0
Supporting protocol for INTERBUSNo
Supporting protocol for PROFIBUSNo
Number of HW-interfaces RS-2320
Supporting protocol for TCP/IPNo
Supporting protocol for SUCONETNo
Number of HW-interfaces other0
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4220
With optical interfaceNo
Supporting protocol for ASINo
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Number of HW-interfaces parallel0
Supporting protocol for CANNo
Supporting protocol for DeviceNetNo
Number of HW-interfaces serial TTY0
Supporting protocol for other bus systemsYes
With PC connectionYes
Supporting protocol for SERCOSNo
Number of analogue outputs1
Supporting protocol for INTERBUS-SafetyNo
Type of converterU converter
Mains frequency50/60 Hz
Application in industrial area permittedYes
4-quadrant operation possibleNo
Number of interfaces PROFINET0
Integrated breaking resistanceNo
Relative symmetric net voltage tolerance10%
Supporting protocol for AS-Interface Safety at WorkNo
Max. output frequency200Hz
Supporting protocol for Foundation FieldbusNo
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net frequency tolerance5%
Max. output at quadratic load at rated output voltage75kW
Supporting protocol for EtherNet/IPNo
Max. output voltage480V
Supporting protocol for PROFINET CBANo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET IONo
Application in domestic- and commercial area permittedYes
Supporting protocol for BACnetNo
Degree of protection (IP)IP55
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage75kW
Nominal output current I2N160A
