GV2G345 | 3 TAP Offs Busbar GV2 63A 45MM Pitch
Code: 1698335
ManufacturerSchneider Electric
Catalog numberGV2G345
TypeGV2G345
CategoryPhase busbar
EAN code3389110556438
Details
- •Low-voltage industrial components
- •Phase busbar
- •1 KOM
- •SCHNEIDER
Technical specifications
InsulatedYes
Rated surge voltage6kV
Type of electric connectionFork
Rated short-time withstand current lcw-kA
ColourBlack
Max. rated operation voltage Ue690V
Conditioned rated short-circuit current Iq11kA
Suitable for number of devices3
Width in number of modular spacings45
Suitable for devices with auxiliary switchNo
Suitable for devices with N-conductorNo
Module width45mm
Number of phases3
Cross section-mm²
Rated permanent current Iu63A
Number of poles3
Length135mm
