Details
- •Low-voltage industrial components
- •Motor starter/Motor starter combination
- •1 KOM
- •SCHNEIDER
Technical specifications
Supporting protocol for ModbusNo
Number of auxiliary contacts as normally closed contact1
Width45mm
Rated operation power at AC-3, 400 V5.5kW
Height224mm
Suitable for emergency stopNo
With transformerNo
Number of command positions3
Rated operation current Ie12A
Number of indicator lights0
Supporting protocol for INTERBUSNo
Overload release current setting- - -A
Depth126mm
Supporting protocol for LONNo
Supporting protocol for TCP/IPNo
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Supporting protocol for PROFIBUSNo
Supporting protocol for ASINo
Supporting protocol for CANNo
Number of auxiliary contacts as normally open contact1
Supporting protocol for DeviceNetNo
External reset possibleNo
Supporting protocol for other bus systemsNo
Rail mounting possibleYes
Rated control supply voltage Us at AC 60HZ- - -V
Supporting protocol for INTERBUS-SafetyNo
With short-circuit releaseYes
Rated control supply voltage Us at AC 50HZ- - -V
Rated control supply voltage Us at DC24 - 24V
Degree of protection (IP)IP20
With fuseNo
Supporting protocol for SERCOSNo
Rated operation current at AC-3, 400 V12A
Type of electrical connection of main circuitScrew connection
Supporting protocol for AS-Interface Safety at WorkNo
Type of electrical connection for auxiliary- and control current circuitScrew connection
Voltage type for actuatingDC
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for Foundation FieldbusNo
Rated power, 460 V, 60 Hz, 3-phase5.5kW
Rated operation power at AC-3, 230 V, 3-phase3kW
Supporting protocol for EtherNet/IPNo
Rated power, 575 V, 60 Hz, 3-phase5.5kW
Supporting protocol for SafetyBUS pNo
Supporting protocol for DeviceNet SafetyNo
Type of motor starterReversing starter
Temperature compensated overload protectionYes
Ambient temperature, upper operating limit70°C
Rated conditional short-circuit current, type 1, 600 Y/347 V4000A
Rated conditional short-circuit current, type 2, 230 V50000A
Coordination class according to IEC 60947-4-3Class 2
Rated conditional short-circuit current, type 2, 400 V50000A
Rated conditional short-circuit current, type 1, 480 Y/277 V10000A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LU2B12BL | Baza 2 Smjera 12A 24VDC
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/Motor starter combination
- 1 KOM
- SCHNEIDER
DetailsTechnical specifications
Technical specifications
Supporting protocol for Modbus
Number of auxiliary contacts as normally closed contact
1
Width
45mm
Rated operation power at AC-3, 400 V
5.5kW
Height
224mm
Suitable for emergency stop
With transformer
Number of command positions
3
Rated operation current Ie
12A
Number of indicator lights
0
Supporting protocol for INTERBUS
Overload release current setting
- .. -A
Depth
126mm
Supporting protocol for LON
Supporting protocol for TCP/IP
Supporting protocol for SUCONET
Supporting protocol for Data-Highway
Supporting protocol for PROFIBUS
Supporting protocol for ASI
Supporting protocol for CAN
Number of auxiliary contacts as normally open contact
1
Supporting protocol for DeviceNet
External reset possible
Supporting protocol for other bus systems
Rail mounting possible
Rated control supply voltage Us at AC 60HZ
- .. -V
Supporting protocol for INTERBUS-Safety
With short-circuit release
Rated control supply voltage Us at AC 50HZ
- .. -V
Rated control supply voltage Us at DC
24 .. 24V
Degree of protection (IP)
IP20
With fuse
Supporting protocol for SERCOS
Rated operation current at AC-3, 400 V
12A
Type of electrical connection of main circuit
Screw connection
Supporting protocol for AS-Interface Safety at Work
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Voltage type for actuating
DC
Supporting protocol for PROFIsafe
Supporting protocol for PROFINET CBA
Supporting protocol for PROFINET IO
Supporting protocol for Foundation Fieldbus
Rated power, 460 V, 60 Hz, 3-phase
5.5kW
Rated operation power at AC-3, 230 V, 3-phase
3kW
Supporting protocol for EtherNet/IP
Rated power, 575 V, 60 Hz, 3-phase
5.5kW
Supporting protocol for SafetyBUS p
Supporting protocol for DeviceNet Safety
Type of motor starter
Reversing starter
Temperature compensated overload protection
Ambient temperature, upper operating limit
70°C
Rated conditional short-circuit current, type 1, 600 Y/347 V
4000A
Rated conditional short-circuit current, type 2, 230 V
50000A
Coordination class according to IEC 60947-4-3
Class 2
Rated conditional short-circuit current, type 2, 400 V
50000A
Rated conditional short-circuit current, type 1, 480 Y/277 V
10000A
