Details
- •Low-voltage industrial components
- •Motor starter/Motor starter combination
- •1 KOM
- •SCHNEIDER
Technical specifications
Depth126mm
With transformerNo
Rated operation power at AC-3, 400 V15kW
Height224mm
Number of command positions3
Width45mm
Number of indicator lights0
Suitable for emergency stopNo
Overload release current setting- - -A
Number of auxiliary contacts as normally open contact1
Supporting protocol for LONNo
Supporting protocol for TCP/IPNo
Rated operation current Ie32A
Number of auxiliary contacts as normally closed contact1
Supporting protocol for INTERBUSNo
Supporting protocol for SUCONETNo
Supporting protocol for CANNo
Supporting protocol for ModbusNo
Supporting protocol for DeviceNetNo
Supporting protocol for other bus systemsNo
Supporting protocol for Data-HighwayNo
Supporting protocol for PROFIBUSNo
Rail mounting possibleYes
Supporting protocol for ASINo
External reset possibleNo
Supporting protocol for SERCOSNo
Rated control supply voltage Us at AC 50HZ- - -V
Supporting protocol for INTERBUS-SafetyNo
Degree of protection (IP)IP20
With short-circuit releaseYes
Rated control supply voltage Us at AC 60HZ- - -V
Rated control supply voltage Us at DC24 - 24V
Type of electrical connection of main circuitScrew connection
Type of electrical connection for auxiliary- and control current circuitScrew connection
With fuseNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET IONo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for SafetyBUS pNo
Voltage type for actuatingDC
Rated operation current at AC-3, 400 V32A
Rated power, 460 V, 60 Hz, 3-phase15kW
Rated operation power at AC-3, 230 V, 3-phase7.5kW
Rated power, 575 V, 60 Hz, 3-phase15kW
Type of motor starterReversing starter
Supporting protocol for PROFIsafeNo
Temperature compensated overload protectionYes
Rated conditional short-circuit current, type 1, 480 Y/277 V10000A
Ambient temperature, upper operating limit70°C
Coordination class according to IEC 60947-4-3Class 2
Rated conditional short-circuit current, type 2, 400 V50000A
Rated conditional short-circuit current, type 1, 600 Y/347 V4000A
Rated conditional short-circuit current, type 2, 230 V50000A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
LU2B32BL | Baza 2 Smjera 32A 24VDC
