Details

  • •Terminal blocks
  • •Feed-through terminal block
  • •Minimum order quantity: 50 pcs
  • •SCHNEIDER

Technical specifications

Mounting methodDIN rail (top hat rail) 35 mm
Inflammability class of insulation material according to with UL94V0
Closing plate requiredYes
Type of electrical connection 1Spring clamp connection
Width5.2mm
Height55mm
Depth78mm
Operating temperature-40 - 130°C
Connectable conductor cross section fine-strand with cable end sleeve0.2 - 2.5mm²
Connectable conductor cross section multi-wired0.08 - 2.5mm²
Internally connected stagesNo
Number of clamp positions per level2
Connectable conductor cross section fine-strand without cable end sleeve0.08 - 2.5mm²
Material insulation bodyThermoplastic
Type of electrical connection 2Spring clamp connection
Explosion-tested version 'Ex e'Yes
Number of levels2
ColourGrey
Rated voltage500V
Connectable conductor cross section solid-core0.08 - 4mm²
Rated current In22A
