Details

  • •Programmable logic controllers PLC
  • •Fieldbus, decentr. periphery - analogue I/O module
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Width128.3mm
Height13.9mm
Suitable for safety functionsNo
Depth70mm
Supporting protocol for CANNo
Number of HW-interfaces RS-4850
Supporting protocol for DeviceNetNo
Supporting protocol for ASINo
Supporting protocol for ModbusNo
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-2320
Supporting protocol for SUCONETNo
Number of HW-interfaces serial TTY0
Supporting protocol for INTERBUSNo
Supporting protocol for TCP/IPNo
Number of HW-interfaces other0
Supporting protocol for PROFIBUSNo
Number of HW-interfaces parallel0
Number of HW-interfaces USB0
Supporting protocol for Data-HighwayNo
Number of HW-interfaces RS-4220
Supporting protocol for KNXNo
Supporting protocol for LONNo
Supporting protocol for other bus systemsNo
Input, voltageNo
Input, currentYes
Input, thermocoupleNo
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
Front built-in possibleNo
Input, resistance thermometerNo
Appendant operation agent (Ex ib)No
Number of interfaces PROFINET0
Output, currentNo
System accessoryYes
Number of HW-interfaces Wireless0
Degree of protection (IP)IP20
Input signal, configurableYes
Explosion safety category for gasATEX gas-ex-protection, Cat. 3G
Appendant operation agent (Ex ia)No
Explosion safety category for dustOther
Input, resistorNo
Type of electric connectionScrew connection
Rail mounting possibleYes
Fieldbus connection over separate bus coupler possibleYes
Output, voltageNo
Output signal configurableNo
Rack-assembly possibleYes
Wall mounting/direct mountingNo
Supply voltage DC24 - 24V
SIL according to IEC 61508None
Analogue outputs configurableNo
Radio standard BluetoothNo
Radio standard GSMNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET CBANo
Supply voltage AC 50 Hz- - -V
Supply voltage AC 60 Hz- - -V
Radio standard UMTSNo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for AS-Interface Safety at WorkNo
Radio standard GPRSNo
Supporting protocol for EtherNet/IPNo
Supporting protocol for PROFINET IONo
Radio standard Wi-Fi 802.11No
Analogue inputs configurableYes
Performance level according to EN ISO 13849-1None
Supporting protocol for DeviceNet SafetyNo
IO link masterNo
Number of analogue inputs2
Number of analogue outputs0
Voltage type of supply voltageDC
Resolution of the analogue inputs12Bit
Resolution of the analogue outputs-Bit
