Details

  • •Programmable logic controllers PLC
  • •Fieldbus, decentr. periphery - analogue I/O module
  • •1 KOM
  • •SCHNEIDER

Technical specifications

Number of HW-interfaces RS-4220
Supporting protocol for LONNo
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-4850
Suitable for safety functionsNo
Number of HW-interfaces RS-2320
Depth70mm
Height18.4mm
Width128.3mm
Number of HW-interfaces serial TTY0
Supporting protocol for Data-HighwayNo
Supporting protocol for CANNo
Supporting protocol for ModbusNo
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetNo
Supporting protocol for KNXNo
Supporting protocol for other bus systemsNo
Input, currentYes
Supporting protocol for ASINo
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Number of HW-interfaces other0
Supporting protocol for TCP/IPNo
Supporting protocol for PROFIBUSNo
Input, resistorNo
Input, voltageNo
Supporting protocol for INTERBUSNo
Input, thermocoupleNo
Output, voltageNo
Output, currentNo
Input signal, configurableYes
Output signal configurableNo
Input, resistance thermometerNo
Explosion safety category for dustOther
Rail mounting possibleYes
Fieldbus connection over separate bus coupler possibleYes
Type of electric connectionScrew connection
Explosion safety category for gasATEX gas-ex-protection, Cat. 3G
Radio standard BluetoothNo
Rack-assembly possibleYes
Appendant operation agent (Ex ib)No
Wall mounting/direct mountingNo
Appendant operation agent (Ex ia)No
System accessoryYes
IO link masterNo
Supporting protocol for AS-Interface Safety at WorkNo
Degree of protection (IP)IP20
Supporting protocol for Foundation FieldbusNo
Front built-in possibleNo
Supporting protocol for EtherNet/IPNo
Number of HW-interfaces Wireless0
Performance level according to EN ISO 13849-1None
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for DeviceNet SafetyNo
Number of interfaces PROFINET0
Radio standard Wi-Fi 802.11No
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for PROFIsafeNo
Supply voltage DC10 - 10V
SIL according to IEC 61508None
Supporting protocol for SafetyBUS pNo
Supply voltage AC 60 Hz- - -V
Radio standard UMTSNo
Supply voltage AC 50 Hz- - -V
Radio standard GPRSNo
Analogue outputs configurableNo
Analogue inputs configurableYes
Radio standard GSMNo
Number of analogue inputs2
Number of analogue outputs0
Voltage type of supply voltageAC/DC
Resolution of the analogue inputs11Bit
Resolution of the analogue outputs11Bit
