Details
- •Programmable logic controllers PLC
- •PLC analogue I/O-module
- •1 KOM
- •SCHNEIDER
Technical specifications
Input, resistance thermometerNo
Height90mm
Number of analogue inputs2
Width23.6mm
Depth70mm
Output, voltageYes
Output, currentYes
Input signal, configurableNo
Input, thermocoupleNo
Input, voltageYes
Number of analogue outputs4
Input, currentYes
Type of electric connectionSpring clamp connection
Explosion safety category for gasNone
Resolution of the analogue inputs12Bit
Resolution of the analogue outputs12Bit
Appendant operation agent (Ex ia)No
Explosion safety category for dustNone
Appendant operation agent (Ex ib)No
Suitable for safety functionsNo
Output signal configurableNo
Input, resistorNo
SIL according to IEC 61508None
Analogue inputs configurableNo
Performance level according to EN ISO 13849-1None
Analogue outputs configurableNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
TM3AM6G | Module TM3-4 Analog Out. 2 Analog In.spr
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Programmable logic controllers PLC
- PLC analogue I/O-module
- 1 KOM
- SCHNEIDER
DetailsTechnical specifications
Technical specifications
Input, resistance thermometer
Height
90mm
Number of analogue inputs
2
Width
23.6mm
Depth
70mm
Output, voltage
Output, current
Input signal, configurable
Input, thermocouple
Input, voltage
Number of analogue outputs
4
Input, current
Type of electric connection
Spring clamp connection
Explosion safety category for gas
None
Resolution of the analogue inputs
12Bit
Resolution of the analogue outputs
12Bit
Appendant operation agent (Ex ia)
Explosion safety category for dust
None
Appendant operation agent (Ex ib)
Suitable for safety functions
Output signal configurable
Input, resistor
SIL according to IEC 61508
None
Analogue inputs configurable
Performance level according to EN ISO 13849-1
None
Analogue outputs configurable
