Details
- •Programmable logic controllers PLC
- •PLC analogue I/O-module
- •1 KOM
- •SCHNEIDER
Technical specifications
Height41mm
Suitable for safety functionsNo
Width35mm
Depth15mm
Input, resistance thermometerNo
Input signal, configurableNo
Output, currentYes
Input, thermocoupleNo
Explosion safety category for gasNone
Type of electric connectionScrew connection
Output signal configurableNo
Output, voltageNo
Input, currentNo
Input, resistorNo
Explosion safety category for dustNone
Input, voltageNo
Appendant operation agent (Ex ia)No
Appendant operation agent (Ex ib)No
Analogue inputs configurableNo
Analogue outputs configurableNo
SIL according to IEC 61508None
Performance level according to EN ISO 13849-1None
Number of analogue inputs0
Number of analogue outputs2
Resolution of the analogue inputs12Bit
Resolution of the analogue outputs12Bit
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
TMC2AQ2C | Cartridge M221-2 Analog Current Outputs
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Programmable logic controllers PLC
- PLC analogue I/O-module
- 1 KOM
- SCHNEIDER
DetailsTechnical specifications
Technical specifications
Height
41mm
Suitable for safety functions
Width
35mm
Depth
15mm
Input, resistance thermometer
Input signal, configurable
Output, current
Input, thermocouple
Explosion safety category for gas
None
Type of electric connection
Screw connection
Output signal configurable
Output, voltage
Input, current
Input, resistor
Explosion safety category for dust
None
Input, voltage
Appendant operation agent (Ex ia)
Appendant operation agent (Ex ib)
Analogue inputs configurable
Analogue outputs configurable
SIL according to IEC 61508
None
Performance level according to EN ISO 13849-1
None
Number of analogue inputs
0
Number of analogue outputs
2
Resolution of the analogue inputs
12Bit
Resolution of the analogue outputs
12Bit
