Details
- •Circuit breakers and fuses
- •Earth leakage circuit breaker with auxiliary device
- •1 KOM
- •EATON
Technical specifications
Built-in depth67mm
Frequency50Hz
Release characteristicB
Rated voltage230V
Current limiting class3
Degree of protection (IP)IP20
Over voltage category3
Pollution degree2
Rated switch current auxiliary device0A
Control voltage type auxiliary equipmentAC
Additional equipment attached at deliveryFire protection switch
Concurrently switching neutral conductorNo
Width in number of modular spacings3
Rated short-circuit breaking capacity according to IEC 60947-20kA
Rated voltage auxiliary device230V
Rated current25A
Number of poles2
Rated fault current0.03A
Leakage current typeAC
Rated short-circuit breaking capacity according to EN 6100910kA
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
AFDD-25/2/B/003
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker with auxiliary device
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Built-in depth
67mm
Frequency
50Hz
Release characteristic
B
Rated voltage
230V
Current limiting class
3
Degree of protection (IP)
IP20
Over voltage category
3
Pollution degree
2
Rated switch current auxiliary device
0A
Control voltage type auxiliary equipment
AC
Additional equipment attached at delivery
Fire protection switch
Concurrently switching neutral conductor
Width in number of modular spacings
3
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Rated voltage auxiliary device
230V
Rated current
25A
Number of poles
2
Rated fault current
0.03A
Leakage current type
AC
Rated short-circuit breaking capacity according to EN 61009
10kA
