Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •EATON
Technical specifications
Supporting protocol for LONNo
Number of HW-interfaces industrial Ethernet0
With control elementYes
Number of HW-interfaces RS-2320
Depth175mm
Number of digital outputs1
Number of analogue inputs2
Number of digital inputs4
Power consumption446W
Number of analogue outputs1
Height273mm
Width129mm
Number of HW-interfaces RS-4851
Number of HW-interfaces RS-4220
Number of HW-interfaces serial TTY0
Number of HW-interfaces parallel0
Supporting protocol for PROFIBUSNo
Number of HW-interfaces USB0
Supporting protocol for ASINo
Supporting protocol for CANYes
Supporting protocol for INTERBUSNo
Supporting protocol for TCP/IPNo
Number of HW-interfaces other0
With optical interfaceNo
Supporting protocol for KNXNo
Degree of protection (IP)IP20
Supporting protocol for ModbusYes
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SERCOSNo
Supporting protocol for SUCONETNo
Mains voltage200 - 240V
With PC connectionYes
Supporting protocol for DeviceNetNo
Supporting protocol for other bus systemsYes
Supporting protocol for Data-HighwayNo
4-quadrant operation possibleYes
Number of interfaces PROFINET0
Max. output frequency500Hz
Mains frequency50/60 Hz
Relative symmetric net voltage tolerance10%
Supporting protocol for AS-Interface Safety at WorkNo
Max. output at quadratic load at rated output voltage5.5kW
Application in industrial area permittedYes
Relative symmetric net frequency tolerance10%
Max. output at linear load at rated output voltage5.5kW
Number of phases input3
Integrated breaking resistanceYes
Type of converterU converter
Application in domestic- and commercial area permittedYes
Number of phases output3
Supporting protocol for DeviceNet SafetyNo
Nominal output current I2N24A
Supporting protocol for PROFINET IONo
Degree of protection (NEMA)Other
Supporting protocol for EtherNet/IPYes
Supporting protocol for SafetyBUS pNo
Supporting protocol for BACnetNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFIsafeNo
Supporting protocol for Foundation FieldbusNo
Max. output voltage250V
