Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Voltage typeAC
Rated voltage240V
Mounting methodDIN rail
Built-in depth70.5mm
Rated current40A
Selective protectionNo
Rated insulation voltage Ui440V
Rated fault current0.1mA
Connectable conductor cross section multi-wired1.5 - 16mm²
Short-time delayed trippingYes
Rated impulse withstand voltage Uimp4kV
Number of poles4
Frequency50/60 Hz
Leakage current typeOther
Ambient temperature during operating-25 - 40°C
RAL-number (similar)7035
Pollution degree2
Connectable conductor cross section solid-core1.5 - 35mm²
Degree of protection (IP)IP20
With interlocking deviceYes
Short-circuit breaking capacity (Icw)10kA
Surge current capacity3kA
Explosion-proofNo
Additional equipment possibleYes
Width in number of modular spacings4
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
FRCmM-40/4/01-G/F
