Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Rated permanent current Iu630A
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V0kW
Degree of protection (IP), front sideIP31
Conditioned rated short-circuit current Iq88kA
Number of poles3
Number of switches-
Rated operating voltage690 - 690V
Number of auxiliary contacts as change-over contact2
Version as maintenance-/service switchNo
Colour control elementGreen
Suitable for intermediate mountingNo
Version as main switchYes
Type of control elementPush button
Suitable for distribution board installationYes
Rated operation power at AC-23, 400 V0kW
Suitable for front mounting centreNo
Suitable for front mounting 4-holeNo
Max. rated operation voltage Ue AC690V
Rated short-time withstand current lcw42kA
Version as emergency stop installationNo
Version as safety switchNo
Type of electrical connection of main circuitRail connection
Motor drive integratedNo
InterlockableYes
Voltage release optionalYes
Suitable for floor mountingYes
Motor drive optionalYes
Device constructionBuilt-in device slide-in technique (withdrawable)
Rated permanent current at AC-21, 400 V0A
Rated permanent current at AC-23, 400 V-A
Switching power at 400 V0kW
Version as reversing switchNo
