Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •EATON
Technical specifications
Number of poles4
Number of auxiliary contacts as normally closed contact0
Rated permanent current Iu1600A
Conditioned rated short-circuit current Iq88kA
Number of auxiliary contacts as change-over contact2
Number of switches-
Number of auxiliary contacts as normally open contact0
Rated operating voltage690 - 690V
Rated operation power at AC-3, 400 V0kW
Degree of protection (IP), front sideIP31
Version as main switchYes
InterlockableYes
Type of control elementPush button
Type of electrical connection of main circuitRail connection
Motor drive integratedNo
Version as emergency stop installationNo
Suitable for floor mountingYes
Version as safety switchNo
Colour control elementGreen
Suitable for front mounting centreNo
Version as maintenance-/service switchNo
Rated operation power at AC-23, 400 V0kW
Rated permanent current at AC-23, 400 V-A
Rated short-time withstand current lcw42kA
Motor drive optionalYes
Suitable for distribution board installationYes
Suitable for intermediate mountingNo
Max. rated operation voltage Ue AC690V
Device constructionBuilt-in device fixed built-in technique
Rated permanent current at AC-21, 400 V0A
Voltage release optionalYes
Suitable for front mounting 4-holeNo
Version as reversing switchNo
Switching power at 400 V0kW
