Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •EATON
Technical specifications
Degree of protection (IP)IP31
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Rated permanent current Iu4000A
Overload release current setting2000 - 4000A
Rated voltage690 - 690V
Adjustment range short-term delayed short-circuit release8000 - 40000A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz105kA
With switched-off indicatorYes
Number of poles3
Type of electrical connection of main circuitRail connection
Type of control elementPush button
Position of connection for main current circuitBack side
Motor drive integratedNo
Number of auxiliary contacts as change-over contact2
With under voltage releaseNo
Motor drive optionalYes
DIN rail (top hat rail) mounting optionalNo
Complete device with protection unitYes
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionNo
Suitable for DIN rail (top hat rail) mountingNo
Adjustment range undelayed short-circuit release8000 - 48000A
