Details
- •Low-voltage industrial components
- •Motor protection circuit-breaker
- •1 KOM
- •EATON
Technical specifications
With integrated auxiliary switchNo
Height297mm
Rated operation power at AC-3, 400 V110kW
Rated permanent current Iu220A
Width140mm
Depth166mm
Number of poles3
Overload release current setting0 - 0A
With integrated under voltage releaseNo
With thermal protectionNo
Rated operation power at AC-3, 230 V55kW
Rated operating voltage690 - 690V
Device constructionBuilt-in device fixed built-in technique
Type of control elementRocker lever
Rated short-circuit breaking capacity lcu at 400 V, AC35kA
Phase failure sensitiveNo
Switch off techniqueElectronic
Type of electrical connection of main circuitScrew connection
Degree of protection (IP)IP20
Adjustment range undelayed short-circuit release440 - 3080A
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
NZMN3-SE220-CNA
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor protection circuit-breaker
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
With integrated auxiliary switch
Height
297mm
Rated operation power at AC-3, 400 V
110kW
Rated permanent current Iu
220A
Width
140mm
Depth
166mm
Number of poles
3
Overload release current setting
0 .. 0A
With integrated under voltage release
With thermal protection
Rated operation power at AC-3, 230 V
55kW
Rated operating voltage
690 .. 690V
Device construction
Built-in device fixed built-in technique
Type of control element
Rocker lever
Rated short-circuit breaking capacity lcu at 400 V, AC
35kA
Phase failure sensitive
Switch off technique
Electronic
Type of electrical connection of main circuit
Screw connection
Degree of protection (IP)
IP20
Adjustment range undelayed short-circuit release
440 .. 3080A
