Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Mounting methodDIN rail
Selective protectionNo
Built-in depth69.5mm
Rated insulation voltage Ui440V
Leakage current typeAC
Rated voltage230V
Surge current capacity0.25kA
Pollution degree2
Width in number of modular spacings2
Short-time delayed trippingNo
Frequency50 Hz
With interlocking deviceYes
Degree of protection (IP)IP20
Rated impulse withstand voltage Uimp4kV
Ambient temperature during operating-25 - 40°C
Connectable conductor cross section multi-wired1.5 - 16mm²
Connectable conductor cross section solid-core1.5 - 35mm²
Additional equipment possibleYes
Number of poles2
Rated current40A
Short-circuit breaking capacity (Icw)6kA
Rated fault current0.3A
Recommended products
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PF6-40/2/03
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Residual current circuit breaker (RCCB)
- 1 KOM
- EATON
DetailsTechnical specificationsRecommended productsFrom same serie
Technical specifications
Mounting method
DIN rail
Selective protection
Built-in depth
69.5mm
Rated insulation voltage Ui
440V
Leakage current type
AC
Rated voltage
230V
Surge current capacity
0.25kA
Pollution degree
2
Width in number of modular spacings
2
Short-time delayed tripping
Frequency
50 Hz
With interlocking device
Degree of protection (IP)
IP20
Rated impulse withstand voltage Uimp
4kV
Ambient temperature during operating
-25 .. 40°C
Connectable conductor cross section multi-wired
1.5 .. 16mm²
Connectable conductor cross section solid-core
1.5 .. 35mm²
Additional equipment possible
Number of poles
2
Rated current
40A
Short-circuit breaking capacity (Icw)
6kA
Rated fault current
0.3A
From same serie
Recommended products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
