Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Mounting methodDIN rail
Built-in depth69.5mm
Rated current80A
Rated insulation voltage Ui440V
Short-circuit breaking capacity (Icw)10kA
Frequency50 Hz
Number of poles2
Leakage current typeAC
Width in number of modular spacings2
Pollution degree2
Degree of protection (IP)IP20
Rated fault current100mA
Surge current capacity0.25kA
Selective protectionNo
Additional equipment possibleYes
Short-time delayed trippingNo
Rated impulse withstand voltage Uimp4kV
With interlocking deviceYes
Ambient temperature during operating-25 - 40°C
Connectable conductor cross section multi-wired1.5 - 16mm²
Connectable conductor cross section solid-core1.5 - 35mm²
Rated voltage400V
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PF7-80/2/01
