Details
- •Circuit breakers and fuses
- •Residual current circuit breaker (RCCB)
- •1 KOM
- •EATON
Technical specifications
Built-in depth69.5mm
Mounting methodDIN rail
Rated current80A
Rated insulation voltage Ui440V
Rated voltage400V
Rated fault current500mA
Number of poles4
Leakage current typeAC
Connectable conductor cross section solid-core1.5 - 35mm²
Short-circuit breaking capacity (Icw)10kA
Rated impulse withstand voltage Uimp4kV
Frequency50 Hz
Selective protectionNo
Pollution degree2
Additional equipment possibleYes
Ambient temperature during operating-25 - 40°C
Degree of protection (IP)IP20
Short-time delayed trippingNo
Surge current capacity0.25kA
With interlocking deviceYes
Connectable conductor cross section multi-wired1.5 - 16mm²
Width in number of modular spacings4
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
PF7-80/4/05
