PL7-B25/1N
Code: 1747490
ManufacturerEaton
Catalog number262742
TypePL7-B25/1N
CategoryMiniature circuit breaker (MCB)
EAN code4015082627423
Details
- •PL7 circuit-breaker, B char, 1+N-pole, Icn=10kA
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB)
- •Minimum order quantity: 1 pcs
- •EATON
Technical specifications
Voltage typeAC
Built-in depth70.5mm
Frequency50 - 60Hz
Rated voltage230V
Width in number of modular spacings1.5
Rated insulation voltage Ui440V
Current limiting class3
Pollution degree2
Number of protected poles1
Degree of protection (IP)IP20
Over voltage category3
Suitable for flush-mounted installationNo
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0kA
Connectable conductor cross section multi-wired1 - 25mm²
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0kA
Ambient temperature during operating-25 - 75°C
Rated impulse withstand voltage Uimp4kV
Additional equipment possibleYes
Connectable conductor cross section solid-core1 - 25mm²
Concurrently switching neutral conductorYes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10kA
Rated current25A
Release characteristicB
Number of poles (total)2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10kA
