1SAP565100R0001 | CP665
Code: 1748576
ManufacturerABB
Catalog number1SAP565100R0001
TypeRecessed mounted monitor
CategoryRecessed mounted monitor
EAN code-
Details
- •CP665 CP600, control panel, TFT grafic display,
- •Programmable logic controllers PLC
- •Recessed mounted monitor
- •Minimum order quantity: 1 pcs
- •ABB
Technical specifications
Built-in depth60mm
Suitable for safety functionsNo
Operating temperature0 - 50°C
With touch screenYes
Number of colours of the display64000
With colour displayYes
Mouse-cursor control integratedNo
Number of function buttons-
With On Screen DisplayNo
Integrated keyboardNo
Horizontal frequency- - kHz
With HW-interface video signal, analogueNo
With HW-interface USBYes
With HW-interface digital video signalNo
Width of the front336mm
With HW-interface PS2No
Front built-in possibleNo
Supply voltage AC 60 Hz- - V
Height of the front267mm
Frame frequency- - kHz
Rail mounting possibleNo
Wall mounting/direct mountingNo
Supply voltage AC 50 Hz- - V
Rack-assembly possibleNo
Supply voltage DC18 - 30V
Type of displayTFT
Number of grey-scales/blue-scales of display-
Screen diagonal13.3inch
Voltage type of supply voltageDC
Number of pixels, horizontal1024
Number of pixels, vertical768
Degree of protection (IP), front sideIP66
