Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Number of analogue outputs1
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-4851
Number of HW-interfaces parallel0
Width105mm
Depth158mm
Number of HW-interfaces serial TTY0
Number of HW-interfaces industrial Ethernet1
Number of digital outputs1
Number of analogue inputs3
Number of HW-interfaces USB0
Height142mm
With control elementYes
Number of HW-interfaces RS-2320
Number of digital inputs6
Supporting protocol for LONNo
Supporting protocol for PROFIBUSYes
Supporting protocol for TCP/IPNo
Number of HW-interfaces other1
Supporting protocol for ASINo
With optical interfaceNo
Integrated breaking resistanceNo
Supporting protocol for INTERBUSNo
Supporting protocol for SERCOSNo
4-quadrant operation possibleYes
Number of interfaces PROFINET0
With PC connectionYes
Mains frequency50/60 Hz
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for SUCONETNo
Supporting protocol for KNXNo
Number of phases output3
Supporting protocol for DeviceNetYes
Supporting protocol for CANYes
Degree of protection (IP)IP20
Type of converterU converter
Supporting protocol for other bus systemsYes
Supporting protocol for Data-HighwayNo
Mains voltage380 - 500V
Number of phases input3
Supporting protocol for ModbusYes
Relative symmetric net voltage tolerance10%
Max. output voltage500V
Max. output frequency599Hz
Supporting protocol for AS-Interface Safety at WorkNo
Degree of protection (NEMA)1
Application in domestic- and commercial area permittedNo
Relative symmetric net frequency tolerance5%
Supporting protocol for SafetyBUS pNo
Supporting protocol for BACnetNo
Nominal output current I2N4.1A
Supporting protocol for PROFINET IOYes
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPYes
Max. output at linear load at rated output voltage1.5kW
Max. output at quadratic load at rated output voltage1.5kW
Supporting protocol for Foundation FieldbusNo
Application in industrial area permittedYes
Supporting protocol for PROFIsafeNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV320U15N4C | ATV320 Compact 1.5KW - 3PH - 380 - 500V
