Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Width105mm
Depth158mm
Height142mm
Number of analogue outputs1
With control elementYes
Number of analogue inputs3
Number of HW-interfaces RS-2320
Number of HW-interfaces industrial Ethernet1
Supporting protocol for LONNo
Number of digital inputs6
Number of HW-interfaces RS-4220
Number of digital outputs1
Number of HW-interfaces RS-4851
Number of HW-interfaces serial TTY0
Supporting protocol for PROFIBUSYes
Supporting protocol for TCP/IPNo
Supporting protocol for CANYes
Supporting protocol for SUCONETNo
Supporting protocol for INTERBUSNo
Supporting protocol for DeviceNetYes
Supporting protocol for ModbusYes
Number of HW-interfaces parallel0
Supporting protocol for Data-HighwayNo
Supporting protocol for ASINo
With optical interfaceNo
Supporting protocol for KNXNo
Number of HW-interfaces other1
Number of HW-interfaces USB0
Supporting protocol for SERCOSNo
Mains frequency50/60 Hz
4-quadrant operation possibleYes
Supporting protocol for other bus systemsYes
Number of interfaces PROFINET0
With PC connectionYes
Type of converterU converter
Supporting protocol for INTERBUS-SafetyNo
Integrated breaking resistanceNo
Application in domestic- and commercial area permittedNo
Supporting protocol for PROFINET CBANo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for EtherNet/IPYes
Max. output at quadratic load at rated output voltage2.2kW
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net voltage tolerance10%
Relative symmetric net frequency tolerance5%
Max. output frequency599Hz
Application in industrial area permittedYes
Supporting protocol for PROFINET IOYes
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Supporting protocol for SafetyBUS pNo
Max. output voltage240V
Degree of protection (NEMA)1
Degree of protection (IP)IP20
Mains voltage200 - 240V
Number of phases output3
Number of phases input1
Max. output at linear load at rated output voltage2.2kW
Nominal output current I2N11A
