Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth232mm
With control elementYes
Width150mm
Height232mm
Number of digital outputs1
Number of analogue inputs3
Number of HW-interfaces RS-4220
Supporting protocol for LONNo
Number of HW-interfaces RS-2320
Number of HW-interfaces industrial Ethernet1
Number of analogue outputs1
Number of digital inputs6
Number of HW-interfaces RS-4851
Supporting protocol for ASINo
With optical interfaceNo
Number of HW-interfaces serial TTY0
Supporting protocol for TCP/IPNo
Number of HW-interfaces USB0
Number of HW-interfaces parallel0
Number of HW-interfaces other1
Supporting protocol for PROFIBUSYes
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Supporting protocol for INTERBUSNo
Supporting protocol for CANYes
Supporting protocol for DeviceNetYes
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Type of converterU converter
Number of interfaces PROFINET0
Supporting protocol for other bus systemsYes
Mains frequency50/60 Hz
Supporting protocol for SERCOSNo
4-quadrant operation possibleYes
With PC connectionYes
Supporting protocol for INTERBUS-SafetyNo
Integrated breaking resistanceNo
Application in domestic- and commercial area permittedNo
Max. output at quadratic load at rated output voltage7.5kW
Max. output frequency599Hz
Application in industrial area permittedYes
Supporting protocol for PROFINET CBANo
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net voltage tolerance10%
Supporting protocol for EtherNet/IPYes
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFIsafeNo
Supporting protocol for BACnetNo
Relative symmetric net frequency tolerance5%
Degree of protection (NEMA)1
Supporting protocol for AS-Interface Safety at WorkNo
Max. output voltage500V
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET IOYes
Degree of protection (IP)IP20
Mains voltage380 - 500V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage7.5kW
Nominal output current I2N17A
