Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Depth249mm
Height385mm
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-4851
Supporting protocol for ASINo
Supporting protocol for TCP/IPNo
Width180mm
Number of HW-interfaces RS-2320
Supporting protocol for CANYes
Number of digital inputs5
With control elementNo
Supporting protocol for PROFIBUSYes
Number of HW-interfaces other1
Number of digital outputs2
Number of HW-interfaces USB0
Number of analogue inputs2
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
With optical interfaceNo
Supporting protocol for LONNo
Number of analogue outputs1
Supporting protocol for ModbusYes
Supporting protocol for KNXNo
Supporting protocol for INTERBUSNo
Supporting protocol for Data-HighwayNo
Supporting protocol for SUCONETNo
Supporting protocol for other bus systemsYes
4-quadrant operation possibleYes
Supporting protocol for DeviceNetYes
Application in industrial area permittedYes
With PC connectionYes
Supporting protocol for INTERBUS-SafetyNo
Number of interfaces PROFINET0
Integrated breaking resistanceNo
Application in domestic- and commercial area permittedNo
Max. output at quadratic load at rated output voltage22kW
Type of converterU converter
Max. output frequency599Hz
Relative symmetric net voltage tolerance10%
Supporting protocol for SERCOSNo
Mains frequency50/60 Hz
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET IOYes
Supporting protocol for BACnetNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPNo
Max. output voltage480V
Supporting protocol for PROFIsafeNo
Supporting protocol for SafetyBUS pNo
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage22kW
Nominal output current I2N50.8A
