Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Width85mm
Height270mm
Number of analogue outputs1
Number of analogue inputs2
Number of HW-interfaces industrial Ethernet0
Number of digital inputs5
With control elementNo
Number of HW-interfaces RS-4851
Supporting protocol for LONNo
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-2320
Number of digital outputs2
Depth232.5mm
Number of HW-interfaces parallel0
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
Number of HW-interfaces other1
Supporting protocol for Data-HighwayNo
With optical interfaceNo
Supporting protocol for PROFIBUSYes
Supporting protocol for ASINo
Supporting protocol for ModbusYes
Supporting protocol for CANYes
Supporting protocol for DeviceNetYes
Supporting protocol for TCP/IPNo
Supporting protocol for INTERBUSNo
Supporting protocol for KNXNo
Supporting protocol for SUCONETNo
Supporting protocol for other bus systemsYes
Supporting protocol for INTERBUS-SafetyNo
With PC connectionYes
Supporting protocol for SERCOSNo
Type of converterU converter
4-quadrant operation possibleYes
Number of interfaces PROFINET0
Mains frequency50/60 Hz
Integrated breaking resistanceNo
Application in industrial area permittedYes
Max. output frequency599Hz
Application in domestic- and commercial area permittedNo
Relative symmetric net voltage tolerance10%
Max. output at quadratic load at rated output voltage2.2kW
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPNo
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net frequency tolerance5%
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFINET IOYes
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFIsafeNo
Max. output voltage480V
Supporting protocol for BACnetNo
Degree of protection (IP)IP20
Mains voltage380 - 480V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage2.2kW
Nominal output current I2N6.6A
