Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Width400mm
Height2350mm
Number of digital inputs6
With control elementYes
Number of analogue outputs2
Number of digital outputs0
Supporting protocol for LONNo
Number of analogue inputs3
Depth669mm
Supporting protocol for TCP/IPYes
Supporting protocol for PROFIBUSYes
Supporting protocol for DeviceNetYes
With optical interfaceNo
Supporting protocol for SUCONETNo
Number of HW-interfaces USB0
Supporting protocol for Data-HighwayNo
Number of HW-interfaces other0
Supporting protocol for KNXNo
Supporting protocol for INTERBUSNo
Number of HW-interfaces RS-4220
Supporting protocol for other bus systemsNo
Number of HW-interfaces serial TTY0
Number of HW-interfaces RS-2320
Supporting protocol for CANNo
Number of HW-interfaces industrial Ethernet1
Supporting protocol for ASINo
Number of HW-interfaces RS-4851
Supporting protocol for ModbusYes
Supporting protocol for SERCOSNo
Supporting protocol for INTERBUS-SafetyNo
Number of HW-interfaces parallel0
With PC connectionNo
4-quadrant operation possibleYes
Mains frequency50/60 Hz
Application in industrial area permittedYes
Number of interfaces PROFINET0
Type of converterU converter
Max. output frequency500Hz
Relative symmetric net voltage tolerance10%
Application in domestic- and commercial area permittedYes
Max. output at quadratic load at rated output voltage110kW
Supporting protocol for SafetyBUS pNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFIsafeNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET IOYes
Supporting protocol for EtherNet/IPYes
Supporting protocol for AS-Interface Safety at WorkNo
Max. output voltage440V
Relative symmetric net frequency tolerance5%
Supporting protocol for PROFINET CBANo
Supporting protocol for BACnetNo
Integrated breaking resistanceNo
Degree of protection (IP)IP54
Mains voltage380 - 440V
Number of phases output3
Number of phases input3
Max. output at linear load at rated output voltage110kW
Nominal output current I2N211A
